JMT 3DR Telemetry Module Replacement APM Pixhawk Wireless wifi Telemetry Data Transmission Support Mobile Phone And Computers

JMT

  • $9.99
  • Save $3.49
Shipping calculated at checkout.


RM1641845738261779

JMT 3DR Telemetry Module Replacement APM Pixhawk Wireless wifi Telemetry Data Transmission Support Mobile Phone And Computers

WIFI Radio Telemetry, replacing the traditional 3DR Radio Telemetry, use mobile phone, tablet, computer as the receiving end, and transfer the real flight attitude of flight controller end and related data information.

After Only need to using the Transmitter and Receiver at the same time after connected. After WIFI data transmission connected with flight control, install ground equipment, use mobile phone search WIFI. No need to distinguish 915 or 433 again, and also no need to choose the baud rate, the default is 57600. And also have one APM and one Pixhawk connecting cables for Telemetry, more convenient for users. External 2.4G soft (IPEX joints) WIFI antenna, 2DB gain (small size) brass antenna, length 10CM, user-friendly installation.
WIFI Radio Telemetry Basic Specifications:
Wireless Standard
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Transmission Rate:
11n: Up to 150Mbps
11g: Up to 54Mbps
11b: Up to 11Mbps
Number of Channels: 1-14
Frequency Range: 2.4-2.4835G
Transmitter power 14-18 DBM
Interface: Serial ports, GPIO
Antenna Type: External antenna
Transmission distance: 300-800 meters (different environmental conditions, different transmission distance)
Function Specifications:
WIFI mode
Wireless LAN / wireless access point
Wireless Security
Wireless security features
64/128/152 bit WEP encryption
WPA-PSK / WPA2-PSK, WPA / WPA2 security mechanism
Transmission rate: 57600bps
TCP connection
Maximum number of connections: 4
Other Specifications:
Status Indicator
Status Indication
Environmental Standards
Working temperature: -20-70 degree
Humidity: 10% -90% RH (non-condensing)
Storage temperature: -40-80 degree
Storage humidity: 5% -90% RH (non-condensing)
Other properties:
Bandwidths optional: 20MHz, 40MHz, automatic
