QWinOut 2306 2400KV Brushless Motor 3~4S + X300 300mm Frame Kit with HULKIE 5055S 3 Paddle Propeller Props for 210 250 280 300 FPV Racer Drone

QWinOut

Regular price $75.70

Shipping calculated at checkout.

QWinOut 2306 2400KV Brushless Motor 3~4S + X300 300mm Frame Kit with HULKIE 5055S 3 Paddle Propeller Props for 210 250 280 300 FPV Racer Drone

Notice: the Propeller color is Red, if you need other color, pls leave a message or contact us

Package included:
1x or 4x JMT H-Motor 2306 2400KV

1X 300mm Frame Kit

2 PairsX 5055S Propellers



300MM Frame Kit:





Stator Diameter

23mm

Stator Thickness

6mm

No. of Stator Arms

12pcs

No. of Stator Poles

14

Motor KV

2400

No-Load Current(11.1V)

1.6A

Motor Resistance

44mΩ(Ref)

Max Continuous Current

50A

Max Continuous Power

750W

Weight

32g

Outside Diameter

28mm

Body Length

17.6mm

Max Lipo Cell

3~4S

ESC

30-50A

Recommended Prop(inch)

5-6 inch Propeller



Advantage:
1, select high-quality materials, high-quality bearings; motor wear is mainly on the bearings, using high-quality bearings to ensure longer motor life
2, high quality magnets stable performance; use high quality silicon steel sheet, high quality magnet to ensure the motor's running performance is more stable
3, precision instrument adjustment balance; In order to ensure better operation of the machine, so that the running equipment to achieve a better state, it is necessary to check the dynamic balance of the rotating body.
4. High performance motors for crossing and tailoring.
2



Adaptation motor: GT2206-2300KV

Color:Red, Yellow, White, Blue,
