TWIG XL 3'' FPV Toothpick Quad-The first joint quad with Racer X FPV, but not the last one.
This TWIG XL X version frame is definitely the most popular frame at present. The performance and power to weight ratio of this frame design is out of this world! With the Caddx Ratel Camera, 1404 3800KV Brushless Motors, 12A Toothpick F4 2-4S AIO FC, it supports 450mAh 4S battery （Package Not included) and provides you a super efficient flight experience. What is more, we adopt the injection molded canopy, protecting your camera well even in a several severe crashing.
Toothpick F4 2-4S 12A AIO FC- Integrated with a Betaflight MATEKF411RX processor FC, Betaflight OSD and 2-4S 12A ESC, support 4S battery for fast-flying experience
Camera & VTX
The Caddx Ratel is a great camera choice for both night flight as well as during the day! Equipped with a high quality 1/1.18" HDR sensor, it provides up to 0.0001 Sensitivity of lux. It is very versatile in that you can switch between PAL and NTSC video and also between 4:3 and 16:9 video formats. Latency is super low at only 8ms.
A01 VTX board is lighter and perfectly suitable for canopy with switchable output power between 25mW and 200mW. SmartAudio is available for VTX remote control in default.
Output power: 25mW and 200mW (Adjustable)
Smart Audio function is included for radio control
Frequency: 5.8GHz 6 bands 37 channels
TWIG XL frames are premium 3mm thick, high-grade T700 carbon cut along the weave and chamfered on both sides interior and exterior edges at .7mm. All the frames are approximately 140mm motor post to motor post and swing up to 3” props. The frames accommodate motor mounting for 4-hole 9x9 or 12x12 motor mounts.
Injection Molded Canopy
The micro canopy specially designed for 19-20mm camera, which adopts injection molded process and PE material, much durable than the original canopy.
