QWinOut DIY ZD850 Frame Kit APM2.8 Flight Control M8N GPS Flysky TH9X Remote Control 3DR Telemetry Motor ESC for RC Hexacopter

QWinOut

  • $477.69
  • Save $83.63
Shipping calculated at checkout.


DIY Drone ZD850 Frame Kit APM2.8 Flight Control M8N GPS Flysky TH9X Remote Control 3DR Telemetry Motor ESC for RC FPV Hexacopter

Note :

  Product is DIY Version, Unassembled Kit and NO Manual, Please take it into account before ordering.

Our technicist will help client to weld the some wiring for ESC and we will test all electronic parts before shipment.

If any Technical questions, Please message us but do not open dispute or leave negative feedback.

Note: The item do not include Battery!



Product Listing :

1.ZD850 Full Carbon Fiber Frame Kit with Unflodable Landing Gear Foldable Arm *1

2.350KV Brushless Disk Motor high Thrust With Mount *6

3.JMT 40A Brushless ESC Speed Controller *6

4.Tarot TL2909 6-axle Hub *1

5.Three-hole High Quality Carbon Fiber1555  CW CCW Propellers *3 Pairs

6. APM2.8 APM 2.8 No Compass Flight Controller Board Bent Pin with Case *1

7.Mini M8N GPS Module NEO-M8N GPS *1

8. 10cm Servo Receiver Extension Lead Wire Cable M/M *1

9. CNC GPS Anti-interference Antenna Mount Holder Stent Case *1

10.3DRobotics 3DR Radio 433MHz Telemetry Kit *1

11. Flysky 2.4G 9ch FS FS-TH9X Transmitter & Receiver Combo*1

11.1m Black and Red 16AWG Silicon Wire Connecting Wire  * 1

12. 4X Hook & Loop Fastening Tape *1

13.XT60 Male with 14AWG Wire 10cm *1







-------APM 2.8 No compass Flight Control --------



APM is an open source flight control, can you play APM well depend on individual ability. Player must have ability of basic understanding of monolithic integrated circuit, c-language, knowledge of electrical,mechanical, and also needs a certain degree of mental capacity, financialand material resources, energy support.If you're not ready, then We recommend that you prepare some introductory information first.

Introduction:aeProduct.getSubject()

aeProduct.getSubject()

Features:

aeProduct.getSubject()aeProduct.getSubject()



----------------------3DR Telemetry Kit -------------



- Very small size
- Light weight (under 4 grams without antenna)
- 433 MHz
- Receiver sensitivity to -121 dBm
- Transmit power up to 20dBm (100mW)
- Transparent serial link
- Air data rates up to 250kbps
- MAVLink protocol framing and status reporting
- Frequency hopping spread spectrum (FHSS)
- Adaptive time division multiplexing (TDM)
- Support for LBT and AFA
- Configurable duty cycle
- Built in error correcting code (can correct up to 25% data bit errors)
- Demonstrated range of several kilometers with a small omni antenna
- Can be used with a bi-directional amplifier for even more range
- Open source firmware
- AT commands for radio configuration
- RT commands for remote radio configuration
- Adaptive flow control when used with APM



- Based on HM-TRP radio modules, with Si1000 8051 micro-controller and Si4432 radio module

aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()
