JMT 20A Brushed ESC Car Motor Speed Controller Bothway With brake function For 1/16 1/18 Car Boat


Regular price $6.87

Shipping calculated at checkout.


20A Brushed ESC Car Motor Speed Controller Bothway with brake function For 1/16 1/18 Car Boat

This version is With brake !
Items :20A
Weight :20g
Dimensions: 35.0*22.0*6.0mm
Working volt(V):4.8V-7.4V
Voltage range(V):4.0V-8.4V
Input signal :PPM
Driver frequency:2KHz
Li-Po :2
Constant current 20A Max 25A< 30s Pulsed 50A< 5s
Li-Poly 2-3 cells; Ni-MH 4-10 cells Auto  Detect
with brake
The male plug connect Motor,the female plug connect Battery


The new 20A ESC has got increased capacity, overheat protection, and smaller size.
Here are more details:
1. The new version chanaged to higher effciency MOSFET;
2.Using more efficinet burning line inductance;
3. The new version can take more pressure, with higher reverse capacitance and Larger capacity;
4. Increasing the capacitance to  eliminate the large back-electromotive force caused by the more inrush, particularly suitable for fast start sports.
