BETAFPV Beta85X 4K Whoop 4S HD Whoop DVR FPV Racing Drone BNF PNP with Tarsier 4K Camera 1105 5000KV Motor 2S F405 FC 16A BLHeli_32 ESC

Beta85X 4K 4S Whoop - it is undoubtedly the smallest 4S 4K drone. Sufficient inventory and prompt delivery.

Bullet Point

F4 V2 FC board has added extra 4 pluggable ports for ESC, VTX, RX and LED board, convenient installation and decreasing the dislocated PIN mounting.
High performance STM32F405 processor FC boards and tuned Betaflight OMNIBUSF4SD (OBSD). Faster input signals with lower latency and higher update rate are reachable.
Using single N-channel MosFETs on ESC board which have a lower inner resistance. It is dual MosFETs on the original BLHeli_32 ESC board.
Soldering with 25V/220uf electrolytic capacitor, for protecting ESC board, reducing the defective rate caused by the instantaneous high voltage.
Installed with Caddx Tarsier 4K camera with ND8 fliter which supports APP setting and switchable resolution setting of 4K, 2.7k, 1440P, 1080P.
Upgraded 1105 motor from 6000KV to 5000KV, with a light weight but definitely will give you extreme power and speed. Motor comes with cable connectors.
Durable and light enough frame is customized for the Beta85X. To increase its stability, we specially add an extra stiffener brace of carbon fiber. Whole drone no soldering or tinkering necessary.
450mAh 4S high rate battery is recommended by default. But pilot could also use their own batteries with battery strap. Optional and affordable.

For 85mm brushless whoop drones, there are 3 versions for your choice - Beta85X FPV, Beta85X HD and Beta85X 4K.This link is for Beta85X 4K.

Specification

BETA85X SPECIFICATIONS

Weight: 88.6g (without battery)
F405 V2 Flight Controller and 16A BLHeli_32 ESC
Motors: 1105 5000KV with connector
Props: 2" 4-Blades Props
Camera: CADDX Tarsier 4K
Canopy: Canopy for Tarsier 4K camera
Receiver option: Frsky XM+ / DSMX / Futaba S-FHSS / Flysky / TBS Crossfire / PNP
Recommend battery: 4S 450mAh Battery(Not including)
5.8G FPV antenna
Flight time: 4min - 6min with 450mAh 4S battery

FC SPECIFICATIONS

Find more details about thisF405 V2 FC in another page.

CPU: STM32F405 (Overclock to 240MHz)
Six-Axis: MPU6000
Size: 26mm x 26mm, whoop mounting pattern
Firmware version: Betaflight OMNIBUSF4SD (OBSD)
OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)

Beta85X 4K Whoop Quadcopter (4S)

ESC SPECIFICATIONS

Find more details about this BLHeli 32 ESC board in another page.

Support BLHELI_32
Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, Dshot1200
Input voltage: 3-4S lipo
Cotinue current: 16A
Peak current: 19A
Firmware target: BETAFPV-16A-32bit
MCU: STM32F051K66

Camera SPECIFICATIONS

Find more details about this Caddx Tarsier 4K camera in another page.

Weight: 19.5g
FOV: 4KF 2.8, FOV 150°(16/9), FPV FOV 165°（4/3）
Lens: Dual lens 2.8 / 12Mega
Image Sensor: 12M SONY sensor
TV System: NTSC / PAL, can be changed
Anti-Shake: Hardware anti-shake
Scene Mode: Auto / Personage / Scenery / Defog
Recording Timing Larm: OFF / 1mins / 3mins / 5mins / 10mins
Horizontal Resolution: 1200TVL
Image: 16:9 / 4: 3 (changeable)
Camera OSD: Seperate OSD
The camera tilt angle is switchable from 20 degree to 30 degree with ND8 fliter.

WHAT HAVE DONE TO SUPPORT 4S?

This Beta85X has upgraded in individual parts like FC, ESC, Motor, which can support 4S power with a steady performance and bring you into a glorious FPV world.

F4 FC & BLHeli_32 ESC

Support 4S Power. Written for ESC's that utilize 32-bit MCU. With the increase in processing power, faster input signals with lower latency and higher update rate would be possible in BLHeli_32, such as Dshot1200!
Using single N-channel MosFETs on ESC board, witch have a lower inner resistance. It is dual MosFETs on the original BLHeli_32 ESC board.
Current sensor included.
ESC is mounted on the frame by screws and connected with FC boards by cables.

Last Version: The performace of the ESC is limitted and could not stand 4S power on 85X for a long time. Besides, the ESC is connected to the FC board by header pins. When pluging the battery, the ESC will loose with the FC board and cause circut shot.

Power Capacitor

Soldering with 25V/220uf electrolytic capacitor, for reducing the defective rate caused by the instantaneous high voltage.

Last Version: Not power capacitor included, which have the risk that the permanently damage on ESC by impulse voltage when plug the battery.

1105 5000KV Motor

Lower 5000KV for new Beta85X 4S, which could support 4S power which won't cause the issue of overheat or burn (maybe the ESC). Also change motor cables from 30AWG to 28AWG.

Last Version: 1105 6000KV motors with 30AWG cables. In 4S power status, the motor will be overheat and damaged. Which may cause the burnt on the ESC.

Frame Stiffener Brace

The stiffener brace of carbon fiber can reinforce the Beta85X frame, avoid unstability caused by too strong power when Beta85x is flying.

Last Version: No stiffener brace included, which would result in seriously vibration on 4S power.

Caddx Tarsier 4K Camera

Tarsier camera is the first DVR boards that could support 4K@30fps recording. Here is the basic manual for you to recording when get this Beta85X 4K drone.

There are 2 buttons on the DVR board. One is for wifi and recording. The other one for power and recording video mode.

	Short Press	Long Press (5-8s)
Wifi/Record Button	Start/Stop Recording	Start Wifi
Power/Mode Button	Switch Video Resolution	Turn on/off Camera

There are 2 LEDs to indicate the recording status.

	Flashing	Flash Solid
Wifi LED	Wifi is power on and not connected	Connected
Mode LED	Recording	Not Recording

Also, there is a CADDX Tarsier APP on Apple Store (for IOS phone) or Google Store (for Android phones). Through the APP, you could change the settings like Metering, White balance, EV compensation, IOS limit, Sharpness, Contrast, Saturation.

Beta85X 4K Whoop Quadcopter (4S)

Video Quality and Shooting Tips

We care about mostly is the video quality of this 4K drones. Here is some you must know about and some advice for a perfect video.

4K@30fps VS 2.7K@60fps

The frames per second of the Caddx Tarsier camera is 30fps on 4K mode. It is suitable to fly slowly and smoothly. But if the drone flys quickly or turns around, the scenes seems be out of focus and fuzzy. At this time, we would high recommend you to shooting in 2.7K@60fps.

Discussion about 4K/2.7K/1080P video quality on Facebook. Do we really need 4K video for micro drone?

Note: How to change the Tarsier mode between 4K and 2.7K?

You should change the recording resolution through the Caddx APP. The other method is just short press Power/Mode Button, as show in the image above. The mode is indicated by the color of the Mode LED.

Mode LED -> Red -> 4K mode

Mode LED -> Green -> 2.7K mode
