Happymodel EX1103 1103 6000KV 7000KV 8000KV 12000KV 2-4S Brushless Motor for Sailfly-X Larva X Toothpick RC Racing Drone FPV Models
Specifications:Mode: EX1103
KV options: 6000KV 7000KV 8000KV 12000KV
Configu-ration:9N12P
Stator Diamter:11mm
Stator Length:3mm
Shaft Diameter: Φ1.5mm
Motor Dimension(Dia.*Len):Φ13.5mm*16mm
Weight(g):3.7g
No. of Cells(Lipo):
6000KV support 3-4S
7000KV support 2-3S original motors for Larva X
8000KV support 2-3S
12000KV support 1-2S

Features:
High efficiency and smooth
Dual bearing design and more balance
Better for Toothpick building
Compatible with 40mm-75mm propellers

Happymodel EX1103 Motor Test
Model	No Load	Propeller	Voltage (v)	Currents (A)	Thrust (g)	Power (W)	Efficiency （g/W)	Throttle
EX1103-6000	0.12A 12080RPM	1935 tri-blades	14.8	1	42.7	14.8	2.885	1399
			14.8	2	74.6	29.6	2.520	1571
			14.8	3	95.3	44.4	2.146	1711
			14.8	4	117.6	59.2	1.986	1827
			14.8	4.4	124.6	65.12	1.913	1922
EX1103-6000	0.14A 11580RPM	65mm bi-blades	14.8	1	53.2	14.80	3.595	1495
			14.8	2	92.5	29.60	3.125	1683
			14.8	3	121.7	44.40	2.741	1829
			14.8	4	148.7	59.20	2.512	1952
			14.8	4.6	157.5	68.08	2.313	2200
EX1103-8000	0.25A 15720RPM	1935 tri-blades	11.1	1	32.8	11.1	2.955	1399
			11.1	2	56.6	22.2	2.550	1571
			11.1	3	76.6	33.3	2.300	1711
			11.1	4	92.8	44.4	2.090	1827
			11.1	5	109.2	55.5	1.968	1922
			11.1	5.9	122.3	65.49	1.867	2200
EX1103-8000	0.20A 15650RPM	65mm bi-blades	11.1	1	36.8	11.1	3.315	1397
			11.1	2	67.3	22.2	3.032	1585
			11.1	3	91.3	33.3	2.742	1707
			11.1	4	111.2	44.4	2.505	1837
			11.1	5	128.3	55.5	2.312	1941
			11.1	5.8	139.1	64.38	2.161	2200
EX1103-12000	0.44A 24750RPM	65mm bi-blades	7.4	1	22.5	7.4	3.041	1298
			7.4	2	40	14.8	2.703	1425
			7.4	3	58.4	22.2	2.631	1554
			7.4	4	72.3	29.6	2.443	1649
			7.4	5	87.6	37	2.368	1750
			7.4	6	98.6	44.4	2.221	1830
			7.4	7	109.3	51.8	2.110	1918
			7.4	8	119.9	59.2	2.025	1988
			7.4	8.3	121.2	61.42	1.973	2200
EX1103-12000	0.44A 24750RPM	1935 tri-blades	7.4	1	18.6	7.4	2.514	1298
			7.4	2	32.8	14.8	2.216	1425
			7.4	3	47.8	22.2	2.153	1554
			7.4	4	59.7	29.6	2.017	1649
			7.4	5	72.4	37	1.957	1750
			7.4	6	83.2	44.4	1.874	1830
			7.4	7	92.6	51.8	1.788	1918
			7.4	8	101.8	59.2	1.720	1988
			7.4	8.2	103.8	60.68	1.711	2200
