QWinOut Full Set DIY FPV Drone Kit S600 4-axis Aerial Quadcopter Pix2.4.8 Flight Control GPS 7M 40A ESC 700kv Motor FS-I6 Transmitter

QWinOut

Sale price $435.57 Regular price ~~$653.36~~

Shipping calculated at checkout.

QWinOut Full Set DIY FPV Drone Kit S600 4-axis Aerial Quadcopter Pix2.4.8 Flight Control GPS 7M 40A ESC 700kv Motor FS-I6 Transmitter

Use Pixhawk PX4 PIX 2.4.8 32 Bit Flight Controller Integrate PX4FMU PX4IO Safety Switch Buzzer 4G SD and 7M GPS

- The board integrates with PX4FMU+PX4IO

- Pixhawk is with new 32 bit chip and sensor technology

Features:

- Advanced 32 bit CortexM4 ARM high performance processor, can run RTOS NuttX real time operating system;

- 14* PWM/ actuator output;

- Bus interface (UART, I2C, SPI, CAN);

- Integrated backup power supply and failure backup controller, the main controller can be safely switched to backup control;

- Provide automatic and manual mode;

- Provide redundant power input and fault transfer function;

- Color LED lamp;

- Multi tone buzzer interface;

- Micro SD to record flight data;

Processor:

- 32 bit 2M flash memory STM32F427 Cortex M4, with hardware floating point processing unit

- Main frequency: 256K, 168MHZ RAM

- 32 bit STM32F103 backup co processor

Sensor:

- L3GD20 3 axis digital 16 bit gyroscope

- LSM303D 3 axis 14 bit accelerometer /magnetometer

- MPU6000 6 axis accelerometer / magnetometer

- MS5611 high precision barometer

Interface:

- 5* UART, 1*compatible high voltage, 2*hardware flow control

- 2* CAN

- DSM/DSM2/DSM-X satellite receiver compatible input

- Futaba SBUS compatible input and output

- PPM signal input

- RSSI (PWM or voltage) input

- I2C

- SPI

- 3.3 and 6.6VADC input

- External USB MICRO interface

All motors and ESC has been Welded before shipping,what you need to do is assemble it and fly

S600 4-Axis Rack Quadcopter Frame Kit with Landing

Specifications:
Wheelbase: 600mm
Weight: 590g
Color: Black
Rack plate thickness: 1.6mm
Motor installation size: 16mm, 26mm

improvement
1. Built-in power distribution board
2. Added flight control shock absorber plate

Flysky FS-i6 6CH 2.4G AFHDS 2A LCD Transmitter iA6 Receiver Mode 2/1 Radio System

Transmitter Specfications:
Channels: 6
Model type: fixed-wing/glider/helicopter
RF range: 2.405-2.475GHz
Bandwidth: 500KHz
Band: 142
RF power: less than 20dBm
2.4G system: AFHDS 2A and AFHDS
Code type: GFSK
Sensitivity: 1024
Low voltage warning: less than 4.2V
DSC port: PS2; output: PPM
Charger port: no
ANT length: 26mm * 2(dual antenna)
Power: 6V 1.5AA * 4 (Not included)
Display mode: Transflective STN positive type,
128 * 64 dot matrix VA72 * 39mm, white backlight.
Size:174 * 89 * 190mm
Weight: 392g
Online update: yes
Color: black

Receiver Specifications:
Channels: 6 Channels
Model type: Airplane / Glider / Helicopter
Frequency range: 2.4--2.48GHZ
Band width number: 140
Transmitting power: not moer than 20dBm
RX sensitivity: -105dBm
2.4G system: AFHDS 2A
Code type: GFSK
Antenna length: 26mm
Input power: 4.0-6.5V DC
Dimension: 40 * 21 * 7mm
Weight: 6.4g
Color: Black
i-Bus interface: No
Data acquisition interface: No

11.1V 4400MAH 30C 3S1P Lipo Battery xt60 Plug and Charger

QWinOut Full Set DIY FPV Drone Kit S600 4-axis Aerial Quadcopter Pix2.4.8 Flight Control GPS 7M 40A ESC 700kv Motor FS-I6 Transmitter

S600 4-Axis Rack Quadcopter Frame Kit with Landing

Specifications: Wheelbase: 600mm Weight: 590g Color: Black Rack plate thickness: 1.6mm Motor installation size: 16mm, 26mm improvement 1. Built-in power distribution board 2. Added flight control shock absorber plate

Flysky FS-i6 6CH 2.4G AFHDS 2A LCD Transmitter iA6 Receiver Mode 2/1 Radio System
