Flycolor Raptor SLIM 40A 2-4S BLHeli-S ESC 3 in 1 Driver IC Support Dshot600 35*10*7mm Mini Size for RC Models
Features:
● Dedicated high frequency driver, makes the start more smooth. ESC maximum speed is 500k eRPM
● BLHeli-S firmware is designed for superior performance in multirotors, and uses hardware generated motor pwm for smooth throttle response and silent operation
● Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
● Supports higher KV motor and more power load, more suitable for violent flight of racing drone
● The code supports regular 1-2ms pulse width PWM input, as well as Oneshot and Multshot . The input signal is automatically detected by the ESC upon power up.
● Supports Dshot150, Dshot300 and Dshot600. Dshot is digital signal, anti-interference ability is stronger, and do not need throttle calibration
● The silicone twisted-pair of the throttle signal cable increase the service life, and effectively reduces the cross-talk caused by signal transmission and makes flight more stable
● Suit 170 200 210 220 250 280 330mm RC FPV Racing Quadcopter
Specifications:
Model: RAPTOR SLIM 40A
Lipo cells: 2-4S
Con.current: 40A
Burst current (10S): 50A
Firmware: BLHeli-S
BEC: NO
Weight: 9.1g
Size: About 35 * 10 * 7mm
Apply for: 170-330mm Multirotor
Package information:
Package size: 12 * 10 * 2cm / 4.72 * 3.93 * 0.78in
Package weight: 15g
Poly bag package
Package list:
1pcs or 4PCS RAPTOR SLIM 40A ESC
