QWinOut DIY Drone Quadcopter T450 450mm Frame kit 920KV CW CCW Motor 9433 Propellers 30A ESC APM 2.8 Flight Controller GPS Compass

QWinOut

Regular price $320.63

Shipping calculated at checkout.

Quantity

xiugai

QWinOut DIY Drone Quadcopter T450 450mm Frame kit 920KV CW CCW Motor 9433 Propellers 30A ESC APM 2.8 Flight Controller GPS Compass

Package includes: (different Combo have different configuration, please choose the combo you want.）
For Combo A - G,It will come with APM 2.8 Flight Control
For Combo H,Combo i,Combo j,it will come with PIX Flight Control

Basic configuration:

(All things are included in combo A-G.)

1 Pcs 450mm Frame kit;

4 Pcs 30A ESC;

3 pairs 9443 propellers;

1 Pcs APM2.8 flight controller + GPS compass;

2 Pairs CW CCW 920kv motors

1 Pcs battery strap

Combo A: Basic configuration + XT60 male connector with 14AWG silicone wire

Combo B: Combo A + 1 Pcs 11.1V 2200MAH Battery + 1 Pcs Charger

Combo C: Combo A + Flysky FS-i6 Transmitter (with IA6 receiver)

Combo D: Combo B + Flysky FS-i6 Transmitter (with IA6 receiver)

Combo E: Combo A + 1 Pcs Gimbal + 1 set Landing Gear

Combo F: Basic configuration+ 1 Pcs 11.1V 3300MAH Battery (with T -type male connector)+ 1 Pcs Charger

Combo G: Combo F+ Radiolink AT9S Transmitter

Combo H: Basic configuration
Combo I: Combo H + 1 Pcs 11.1V 2200MAH Battery + 1 Pcs Charger

Combo J: Combo I + Flysky FS-i6 Transmitter (with IA6 receiver)

Frame:

Wheelbase: 450mm

Body board material: glass fiber

Body panel thickness: 2mm

Weight: 307g

Applicable paddle: 9 inch-11 inch

Applicable motor: 1400KV-1000KV

Applicable ESC: 20A-40A

ESC:

Simonk Firmware 30A Electric Speed Controller with 5V 3A BEC

Weight: 25 g

Input voltage:2-4S

Working current:30A

BEC output: 5V 3A

Motor:

KV: 920KV

Outer diameter: 28.0 mm

Height: 24.0 mm (Without Shaft)

Flight controller: APM2.8

Size: 70*45*13.5

Weight: 28G

Features:

- Arduino Compatible!

- Can be ordered with top entry pins for attaching connectors vertically, or as side entry pins to slide your connectors in to either end horizontally

- Includes 3-axis gyro, accelerometer and magnetometer, along with a high-performance barometer

- Onboard 4 MegaByte Dataflash chip for automatic datalogging.

- Optional off-board GPS, uBlox LEA-6H module with Compass.

- One of the first open source autopilot systems to use Invensense's 6 DoF Accelerometer/Gyro MPU
