Steam-RC Rechargeable Smart Digital Pitch Gauge/ Pitch Measuring Instrument Ruler for RC Helicopter

It is suitable for helicopter rotor Paddle with root thickness of 5mm/8mm/10mm/12mm/14mm/[root thickness of 2.5mm-5mm and mounting holes ≥M2.5] to measure the angle. The metal parts are made of 6061T6 aluminium alloy with high precision 5-axis CNC machining.

  The top digital display inclination box has magnetic adsorption measuring surface function, two measuring angles, one key to switch two units slope and angle. With compatibility-Type-C charging cable, with charging function, no need to worry about the battery failure in use.LCD LCD high-definition display, with backlight function, in the sunlight can still see clearly.

This mini digital inclinometer/pitch gauge HOT100006 can measure the tail rotor angle.

(When measuring the tail rotor angle, the levelling bubble needs to be placed horizontally.)

Before use, place the bottom of the pitch gauge on the motor or other relatively flat part of the helicopter. In the power on state, press the power on button on the top of the digital tilt box, the number on the screen will change to ‘0.00’ and the character ‘REF’ will be displayed.

If the measurement is of the main rotor, then the angle value obtained is the pitch angle by increasing or decreasing the metal piece according to the thickness of the paddle root and by nesting the metal piece into the main rotor clamp seat.

If you are measuring the tail rotor, remove the bottom metal piece first to reduce the weight and interference.

According to the mounting holes of the paddle root, choose M2.5 or M3 holes, choose the corresponding screws, take out the unsuitable screws, extend the back of the L-shape base plate into the tail rotor clamp seat, and tighten the screws.

Related Product Numbers:

Mini Digital Inclinometer / Pitch Measuring Instrument HOT100006

Three generations of intelligent digital pitch gauge/green HOT100008-A

Three generations of intelligent digital pitch gauge / red HOT100008-B

Three generations of intelligent digital pitch gauge / titanium HOT100008-C

Product Specification:

Digital tilt box（36.0×36.0×20.0mm）×1

L-shaped base plate (27.0×29.0×29.0mm) × 1

Metal piece (48.0×26.0×8.0mm) ×1

Metal piece（30.0×22.0×2.0mm）×3

M3.0×10mm hexagon socket head cap screw×1

M3.0×28mm cup head socket screw×1

M3.0 nut×1

M3.0×5mm hexagon socket head cap screws×2

M2.5×8mm cup head hexagon socket screws×1

M3.0×10mm cup head hexagon socket screw×1

Gasket (Φ3.0×Φ6.0×0.25mm)×2

Magnet (Φ4.0×12.0×2.0mm) ×1

Horizontal bubble×1

Charging cable×1
